Wall Washer Series FDCB557-12W
Technical Data
Code:FDCB557-12W
Name:Wall Washer Series
LED Type:COB
Driver:FIAM Driver
Luminous Flux:1200Lm
Finishwhite/Black
Size:ø82×H81mm
Cutout:ø75mm
Beam Angle:15°/24°/36°/55°
Color Temperature:3000K-6000K
IP Classification:20
DimmableNO
InstallationRecessed downlight
Operating Temperature-20°C till+40°C
Life Time50,000hrs
